I. Advantage Of Products:
1, High speed transmission
2, Forming system of cassette box
3, PLC control
4, Replaceable roll assembly
5, Fast locking system
6, PLC reinforcement device
7, Cast steel body for a long time without deformation
8, automatic roll out of equipment
9, can produce a variety of different diameter spiral tube
II. Main Technical Parameters:
Diameter range: 80-1600mm
Thickness range: Galvanized plate: 0.4-1.3mm
Stainless steel: 0.4-0.8mm
Material width: 137mm
Sealing & Locking: outer surface of the pipe
Cutter: Rolling type cutting
Power system: Pneumatic power for cutting turning material; Hydraulic power for discharge and roller compression.
Forming head mold: Made of steel(aluminum alloy casting optional)
Total weight: 2900kg
Equipment sizes: Main machine:2*1.7*1..45m(Host)
Discharge rack:2.45*1.2*1.2m(Discharging frame)
Total power: 11KW
Power supply: 380V/50Hz/3ph ( other power supply optional )
Control console: touch screen
III. Speed(3 meter tube):
Thickness:0.5mm,Diameter:100mm¡ª¡ª-250pcs/H
Thickness:0.7mm,Diameter:500mm¡ª¡ª-85pcs/H
Thickness:0.9mm,Diameter:1250mm¡ª¡ª40pcs/H
Thickness:1.25mm,Diameter:1600mm¡ª¨C24pcs/H
IV. Main Import Configuration:
Taiwan Delta Or Germany SIEMENS PLC
Snyder electric appliance
Germany SIEMENS motor
Full imported bearing steel press wheel
V.Cutting mode
Fly Cutter
Plasma Cutter
