Main technical parameters:
| Item | H-10 Duct seam closer |
| Sheet Thickness | 0.5-1.0mm |
| Min.Duct Dimensions | 100x100mm |
| Speed Approx. | 15m/min |
| Support Height up to | 700mm |
| Support Length | 1500mm |
| Number of Support Arms | 2×3 |
| Working Height | 800mm |
| Motor | 2.2kw |
| Weight | 850kg |
| Dimension | 5400x900x1100mm |
Reminder: A machine can only make one lock function, please choose the function that meets your requirements.
